Super Duplex F51 Steel Plate Flanges

Zhejiang ChengyuanSuper Duplex F51 Steel plate flangesIntroduction

The flange is a type of pipe fitting that is used to connect pipes or to close the end of a pipe. There are various types of flanges available, including flat welded flanges, butt-welded flanges, loose sleeve flanges, socket welded flanges, threaded flanges, blind flanges, orifice flanges, sliding sleeve flanges, thread flanges, manhole flanges, eight blind flanges, socket flanges, integral flanges, and more.

Zhejiang ChengyuanSuper Duplex F51 Steel plate flangesParameter (Specification)

The size range of flanges is DN15 to DN1500, with wall thickness pressure grades ranging from 2-42MPa and 2-50mm. Flanges can be made from various materials such as carbon steel, alloy steel, and stainless steel, with examples of materials including 316L, Q235, A694, F52, Q345, A182, F9, 20#, A105, 1Cr18Ni9Ti, 0Cr18Ni9, 00Cr19Ni10, 00Cr17Ni14Mo2, 301, 310, 304, 304L, 18-8, 321, 316, 316L, 2520A403, and more.

Zhejiang Chengyuan Super Duplex F51 Steel plate flangesFeature And Application

The flange is widely used in various industries such as petroleum, chemical, aerospace, power stations, energy, environmental protection, boilers, heat exchangers, ships, subways, pharmaceuticals, breweries, construction, engineering, and more. The main products of flanges include carbon steel pipe fittings, special-shaped tubes, alloy pipes, high-pressure pipes, large-diameter thick-walled tubes, large-diameter thick-wall elbows, elbows, high-pressure thick-wall elbows, alloy elbows, tees, caps, reducers, heads, flanges, valves, compensators, forging tees, forging bends, forged pipe caps, flanges, large taper pipes, conical reducers, and more.

Zhejiang ChengyuanSuper Duplex F51 Steel plate flangesDetails

Zhejiang ChengyuanSuper Duplex F51 Steel plate flangesPROCESS flow
